Adjustable Multipurpose Ball Mount (2″ Shank, 2″ & 2-5/16″ Balls)

If you own multiple trailers or frequently tow a variety of loads, you know how much time and money are spent tailoring your towing system to each and every individual trailer. There is nothing more inconvenient than switching back and forth between a few different ball mounts and trying to remember which mount fits with which trailer. A CURT adjustable ball mount is your multipurpose towing solution. This CURT adjustable ball mount has a shank size of 2" x 2" and features two different trailer ball sizes to accommodate two different coupler sizes: 2" and 2-5/16". The 2" trailer ball offers a gross trailer weight capacity of 7,500 lbs. and a tongue weight capacity of 750 lbs., while the 2-5/16" ball offers 10,000 lbs. GTW and 1,000 lbs. TW. This allows you to easily tow a variety of heavyweight trailers and to ensure that each one tows smoothly and securely. This special ball mount also features an adjustable shank assembly with multiple mounting holes for varying ball heights. Each trailer ball can be raised to a maximum of 6-11/16" rise or lowered to a maximum of 6-1/2" drop, allowing you to make your trailer completely level in any towing situation. It includes three 5/8" hitch pins for quick and secure installation, and comes equipped with a clevis bar to accept a lunette ring. Also, the adjustable shank can also be used with our tri-ball attachment #45800 and #45802 for even more versatility. All CURT adjustable ball mounts are made with sturdy steel construction and come with a durable powder coat finish for long-lasting rust, scratch and UV resistance.

Additional Attributes:

GTIN: 00612314450497
Ball 1 Diameter and Capacity: 2 IN – 7,500 LB
Ball 2 Diameter and Capacity: 2-5/16 IN – 10,000 LB
Ball Diameter: 2 IN or 2-5/16 IN
Container Volume Cubic Feet – XA: 0.00000
Container Volume Cubic Meter – XA: 0.00000
Finish – XA: GLOSS BLACK POWDER COAT
Gross Trailer Weight (GTW): 10,000 LB
GTW/TW Ball 1: 7,500 LB / 750 LB
GTW/TW Ball 2: 10,000 LB / 1,000 LB
Item Class – XA: OBS
Item Height – XA: 0.000
Item Length – XA: 0.000
Item Width – XA: 0.000
Master Case Height Inches – XA: 5.375
Master Case Length Inches – XA: 13.375
Master Case Qty – XA: 1
Master Case Volume Cubic Feet – XA: 0.00000
Master Case Weight Lbs – XA: 40.300
Master Case Width Inches – XA: 10.000
Material – XA: Blank
Max Drop: 6-1/2 IN
Max Rise: 6-11/16 IN
Mount Type Description – XA: Blank
Pallet Qty – XA: 4.000
Pallet Total Height Inches – XA: 0.000
Pallet Total Weight Per – XA: 0.000
Parcel Allowed – XA: Yes
Product Weight – XA: 0.000
Prop 65 Label Text – XA: Blanks
Prop 65 Material – XA: Unknown
Prop 65 Reason – XA: Unknown
Prop 65 Warning Label Type – XA: Unknown
Prop 65 Warning Y/N – XA: NO
Rate Class – XA: 60.0
Receiver Tube Size: 2 IN
Retail Height – XA: 5.910
Retail Length – XA: 14.570
Retail Width – XA: 10.630
Sales Family Code – XA: ACCES
Sales Family Description – XA: ACCESSORIES
Sales Group Description – XA: BALL MOUNT
Shipping Weight – XA: 40.340
Side Application Type Description – XA: Blank
Tariff 301 – XA: Yes
Truckload Volume Cubic Feet – XA: 0.00000
Warranty: Limited Lifetime Warranty (One-Year Finish, One-Year Parts)

Extended Information:

Emissions : Emissions Compliance Exempt
Life Cycle Status: Available To Order

Packaging:

Quantity of Each: 1.0
Package UOM: EA
Dimension: 14.5700 x 10.6300 x 5.9100 inches
Weight: 40.3400 PG
